UTE 4800-R-RAL9010-G-55
Flush-mounted clock thermostat as room controller, RAL9010 glossy 55x55, AC 230V, 1 NO contact, 10A, white backlighting
| Article number | 527810455504 |
|---|---|
| Contact | Heating |
| Voltage | 230V AC 50/60 Hz |
| Switching current | 10 mA … 10 (4) A 230 V~ |
| Colour | polar white (similar to RAL 9010) |
| Temperature range | 5 … 30°C |
| Measurements | 55 x 55 mm |
| Technology | Electronic |
| Temperaturedrop | Yes |
| Surface | glossy |
| Control procedure | PWM / ON/OFF (adjustable) |
| Display | Yes |
| Programmable | Yes |
| Remote sensor | optional |
| Switch | |
| LED | Heating / temperature setback |
Flush-mounted clock thermostat suitable for all standard switch ranges. Polar white/glossy, 55x55 cover without frame. Suitable for controlling central heating, hot water underfloor heating, warm air heating, etc. Very large display, backlighting in white is off, briefly on at the touch of a button. Single-line text display for self-explanatory operation. Automatic summer/winter time changeover. Preset and customizable lifestyle time programs. Unauthorized access protection. Optimum start (temperature is reached at the set time). Max. 9 switching times per day. Short-term timer (party) for hourly temperature changes. Frost protection function. Temperature setting range can be limited. Valve protection. PWM or 2-point control method. Heating/cooling changeover, adaptation to valves normally open. Energy consumption display (switch-on x costs). Installation in 55 mm flush-mounted box
